FLUIDISED BATH TECHNE SBL-2D 50º TO 600ºC 220-240V 50/60HZ

FLUIDISED BATH TECHNE SBL-2D 50º TO 600ºC 220-240V 50/60HZ

Product Code: BK512-12

Manufacturers Code: F946D

£6,078.00

inc. VAT

£5,065.00

ex. VAT

Download Product Information

SB-series fluidised baths

High temperature  dry baths which are pollution free and safer replacements for traditional oil and salt baths.

A fluidised bath consists of a loosely packed mass of solid particles through which an upward flow of gas is passed. In this fluidised state the particles become mobile, and the bath as a whole displays many of the properties of a liquid. However, since the bath is composed of tiny inert aluminium oxide particles, freezing, boiling and evaporation are totally eliminated.

The dry, inert particles do not adhere to immersed objects, neither do they cause corrosion. The particles have a gentle motion that is non-abrasive.

The mobility of the bath ensures rapid heat transfer and excellent temperature uniformity.

These baths require a clean air supply at a pressure of 21KN/m2  (3psi) and maximum flow of 57 litres/minute.

General specifications:

 Model

 SBL-2D
 Temperature range
 ºC
 50 to 600
 Stability at 50ºC
 ±ºC
 1
 Tank internal depth x diameter
 mm
 350 x 228
 Power rating
 kW
 4 x 1
 Overall diameter x height
 mm
 385 x 695
 Weight
 kg
 68















For 220-240V 50/60Hz single phase supplies. Without air supply or alundum fluidising media - details on request.
