MELTING POINT APPARATUS STUART SMP20 230V 50HZ A.C.

MELTING POINT APPARATUS STUART SMP20 230V 50HZ A.C.

Product Code: MG165-10

Manufacturers Code: SMP20

£1,036.80

inc. VAT

£864.00

ex. VAT

Download Product Information

An enhanced model, with additional features to improve functionality and ease of use.

  • Maximum temperature 300°C
  • Digital temperature setting and control
  • 4 digit LED display and adjustable resolution 0.1/1°C
  • Pt100 temperature sensor
  • ‘Hold’ button freezes the display when pressed at viewed melting point
  • Two heating ramp rates selectable:
    • 20°C/minute to plateau temperature
    • adjustable ramp rate 1 to 10°C/minute to melt
  • Accepts up to 2 sample tubes
  • Built-in sample illumination
  • Extendible rear feet for optimal viewing angle

Maximum temperature 300°C. Accuracy ±1°C at 20°C, ±2.5°C at 300°C. With Pt100 sensor, digital setting, control adjustable to 0.1/1°C, and 4 digit LED readout. Overall 160 x 220 x 170mm W x D x H. Weight 1.8kg. For 230V 50Hz single phase supplies, 75W. Supplied with calibration certificate and 100 melting point tubes, closed one end.
