MELTING POINT APPARATUS MP-400D 230V 50HZ A.C.

MELTING POINT APPARATUS MP-400D 230V 50HZ A.C.

Product Code: MG170-35

Manufacturers Code: 03011-49 (formerly Stuart SMP30)

£2,316.55

inc. VAT

£1,930.46

ex. VAT

Download Product Information

  • Maximum temperature 400°C x 0.1˚C resolution
  • Accepts up to 3 sample tubes
  • ‘Plateau facility’ gives adjustable ramp rate between 0.5˚C and 10˚C per minute in 0.1˚C increments
  • Memory storage available to record up to 8 temperature event values from each sample
  • Integrated cooling: 350˚C to 50˚C in 20 minutes
  • 2-stage adjustable folding viewing head (height and angle) with head-up display indicating block temperature, visible through the eyepiece in front of the sample tubes
  • Pt1000 temperature sensor
  • Sample tubes illuminated by white LED’s to maximise visibility of the melt
 Model      MP-400D
 Range            Ambient to 400oC
 Accuracy           ±0.5oC at 50oC
    ±2.5oC at 360oC
 Ramp rate   0.5 to 10oC per minute
 Memory           Up to 8 readings per sample
 Capillary tubes          Up to 3, 2mm i.d. maximum
 Overall W x D x H      mm    170 x 200 x 325
 Weight kg 3.6







Supplied with calibration certificate and 100 melting point tubes, closed one end. For 230V 50Hz single phase supplies.
